82 MS-5UD & MS-10UD Series Manual — P/N 52626:C7 6/12/2018
Programming Master Programming Level
Phone Number
Pressing 1 while viewing Primary/Secondary Screen #2 will cause the following screen to be displayed:
The Phone Number screen is used to enter the Central Station phone number that the DACT will be contacting. A maximum of 20 char-
acters can be entered with valid entries being 0 - 9 and A - C where A = *, B = # and C = look for secondary dial tone for up to 2 seconds
(then dial anyway).
A flashing cursor will appear in the lower left corner of the screen. Enter the first digit then press the right arrow key to move the cursor
to the right one position. Enter the second digit and repeat the process until all digits are entered. Press the Enter key to store the phone
number in memory.
Enter the digits as you would like the number to be dialed. For example, if it’s necessary to dial 9 before dialing a number outside the
building, you may wish to pause after dialing 9. Enter 9 followed by D for a three second pause, or E for a five second pause then the
phone number followed by an F to indicate the end of the number.
CENTRAL STATION
1=PHONE NUMBER
Primary/Secondary Screen #2
PHONE NUMBER
20 NUMBERS MAXIMUM
Phone Number Screen
To Next Page
