Honeywell Galaxy - Appendix J: Data Ranges

Page 75
Appendix J : Data Ranges
User Code Ranges
Software Version Panel Type
1.xx 2.xx 3.xx 4.xx 5.xx
G 8 1-10 1-10 1-10 1-50 N/A
G 18 1-20 1-10 1-10 1-100 N/A
G 60 1-30 1-10 1-10 1-200 N/A
G 128 N/A 1-50 1-50 1-250 N/A
G 500 1-100 1-100 1-100 1-500 N/A
G 504 N/A 1-200 1-500 1-999 N/A
G 512 1-200 1-200 1-500 1-999 N/A
G 3-144 N/A N/A N/A N/A 1-250
G 3-520 N/A N/A N/A N/A 1-199
Max Code Ranges
Software Version Panel Type
1.xx 2.xx 3.xx 4.xx 5.xx
G 8 11-20 11-20 11-20 N/A N/A
G 18 21-40 21-40 21-40 N/A N/A
G 60 31-73 31-73 31-73 N/A N/A
G 128 N/A 51-100 51-100 N/A N/A
G 500 101-150 101-150 101-150 N/A N/A
G 504 N/A 200-275 500-575 N/A N/A
G 512 200-275 200-275 500-575 N/A N/A
G 3-144 N/A N/A N/A N/A N/A
G 3-520 N/A N/A N/A N/A N/A
Note: It is best to copy/overwrite the whole range of maxes as they are done in groups of 4.
Zone Ranges
Software Version Panel Type
1.xx 2.xx 3.xx 4.xx 5.xx
G 8 1011-1018 1011-1018 1011-1018 1011-1018 N/A
G 18 1001-1028 1001-1028 1001-1028 1001-1028 N/A
G 60 1001-1078 1001-1078 1001-1078 1001-1078 N/A
G 128 N/A 1011-2078 1011-2078 1011-2078 N/A
G 500 1011-4158 1011-4158 1011-4158 1011-4158 N/A
G 504 N/A 1011-4158 1011-4158 1011-4158 N/A
G 512 1001-4158 1001-4158 1001-4158 1001-4158 N/A
G 3-144 N/A N/A N/A N/A 0011-0018, 1011-2078
G 3-520 N/A N/A N/A N/A 0011-0018, 1001-4158
RIO Output Ranges
Software Version Panel Type
1.xx 2.xx 3.xx 4.xx 5.xx
G 8 1001-1014 1001-1014 1001-1014 1001-1014 N/A
G 18 1001-1024 1001-1024 1001-1024 1001-1024 N/A
G 60 1001-1074 1001-1074 1001-1074 1001-1074 N/A
G 128 N/A 1001-2074 1001-2074 1001-2074 N/A
G 500 1001-4154 1001-4154 1001-4154 1001-4154 N/A
G 504 N/A 1001-4154 1001-4154 1001-4154 N/A
G 512 1001-4154 1001-4154 1001-4154 1001-4154 N/A
G 3-144 N/A N/A N/A N/A 0011-0014, 1001-2074
G 3-520 N/A N/A N/A N/A 0011-0018, 1001-4154
Link Ranges
Software version Panel Type
1.xx 2.xx 3.xx 4.xx 5.xx
G 8 N/A N/A N/A N/A N/A
G 18 1-16 1-16 1-16 1-32 N/A
G 60 1-32 1-32 1-32 1-64 N/A
G 128 N/A 1-64 1-64 1-128 N/A
G 500 1-99 1-99 1-99 1-256 N/A
G 504 N/A 1-99 1-99 1-256 N/A
G 512 1-99 1-99 1-99 1-256 N/A
G 3-144 N/A N/A N/A N/A 1-128
G 3-520 N/A N/A N/A N/A 1-256
