Web Operation | 159
800-18160 - B - 07/2014
Figure 5-24 Video Overlay Configuration Interface
Configuring the Save Path
Click Path in the Video&Audio configuration interface to open the Path configuration interface.
Table 5-10 Video Overlay Configurations
Configuration Description
Channel Select a channel from the drop-down list.
Cover-Area Click to enable the Monitor.
Click Set to configure a privacy mask for the Preview or Monitor.
The system supports up to four privacy mask zones.
Channel Display Enable this function to overlay channel information on the video
window.
Use the mouse to drag the channel title to the desired position.
View the channel title on the live web client video or the playback
video.
Time Display Enable this function to overlay time information on the video
window.
Use the mouse to drag the time display to the desired position.
View the time display on the live web client video or the playback
video.
