162 | Performance Series Full PoE Network Video Recorder User Guide
Guidelines for Connecting Local Alarm Input Ports
• Ground alarm inputs. Choose from normally open (NO) or normally closed (NC).
• Connect the COM end and GND end of the alarm detector in parallel. Supply external
power to the alarm detector.
• Connect the ground of the NVR and the ground of the alarm detector in parallel.
• Connect the NO/NC port of the alarm sensor to the NVR alarm input.
• Use the same ground as the NVR if you are supplying external power to the alarm device.
Guidelines for Connecting Alarm Output Ports
• Provide external power to external alarm device.
• To prevent overloading, carefully review the following relay specifications:
Material
Nickel/silver contacts with gold plating
Rating (Resistance
Load)
Rated switch capacity 30 V DC 1A; 125 V AC 0.5A
Maximum switch power 62.5 V AC, 30 W
Maximum switch voltage 125 V AC; 60 V DC
