166 | Performance Series Full PoE Network Video Recorder User Guide
Figure B-6 Replacing the NVR Cover
7. Secure the NVR cover in place by turning the screws in the rear and side panels.
Figure B-7 Securing the NVR Cover
Installing an additional HDD
1. If the NVR is connected to a power source, disconnect it before continuing.
2. Remove the top cover from the NVR housing by removing the four screws securing it to
the housing and then sliding the cover backwards.
3. Connect the SATA and power cables to the new HDD.
4. Position the new HDD over the four open screw holes in the base of the housing, adjacent
to the existing HDD.
Figure B-8 Installing a Second HDD
