Fire Alarm Control Panel LT-32 / LT-159
M-168.1-SERIE-LT-EN / 08.2022 13
4.2 Electrical specifications
• External power supply: 100 ... 240 Vac, 50 ... 60 Hz
• Power connection terminal: European standard AC. UK connector optional
• Maximum power consumption: 24 W
• Supervised sounder outputs (1 in the LT-159, 2 in the LT-32), each with max. 50 mA
• Max. 500 m distance depending on the cable section and current consumption in alarm
• 1 Alarm relay with configurable NC/NO contact
• 1 Fault relay with configurable NC/NO contact
4.3 Environmental specifications
• Climate classification: K5 (IEC 721-2-3)
• Temperature range: -5ºC ... 40ºC
• Relative humidity: 5% ... 95% non-condensing
• Control panel protection rating: IP 30 (acc. EN 60529)
