Fire Alarm Control Panel LT-32 / LT-159
M-168.1-SERIE-LT-EN / 08.2022 53
14.7 System test – outputs
1. Follow the steps to enter in “Configuration” menu, select “Test" to access to the related options, then select “Outputs” icon to view the list of the addressable
Outputs installed in the system.
2. Click on the empty circle near the output you would like to activate it. In this example, we are activating the Output with address 002.
3. To end the Output test, press on the full dot. Press the back arrow to go back to the main screen.
