Fire Alarm Control Panel LT-32 / LT-159
50 M-168.1-SERIE-LT-EN / 08.2022
14.4 System status – history log
1. Follow the steps to enter in “Configuration” menu, then select “Log“
2. The events are shared in sequence, the latest is on top and the oldest is on the bottom of the list. Are shown date and time of the events, the type of the events,
the Zone number and the related device address. Are also shown the commands released from the panel.
The arrows indicates:
• ↑ an event has started
• ↓ an event is finished
• → a command from the panel was released
3. Press the back arrow to go back to the main screen.
