Fire Alarm Control Panel LT-32 / LT-159
M-168.1-SERIE-LT-EN / 08.2022 23
7.2 LT-32 setup and connections overview
Fig. 16: LT-32 setup and connections overview
Relay Setup
7 Sounder 2 +
8 Sounder 2 -
9 Sounder 1 +
10 Sounder 1 -
Batteries connected in two rows with polarity as shown.
• When the front cover is opened a tamper fault is reported. Fault is reset automatically once the cover is closed again.
• The connections shown have the purpose to underline the differences with LT-159.
