Honeywell Notifier MODBUS-GW User Manual

10 MODBUS-GW Installation and Operation Manual — P/N LS10015-000NF-E:C2 4/30/2019
Product Overview System Architecture
1.8 System Architecture
An Internet or Intranet IP network connection is used with the architectures described in Figures 1.1 and 1.2.
Figure 1.1 Single Panel Architecture
Figure 1.2 NFN Network Architecture
Modbus/IP Client
FACP
NUP
IP Network
EthernetEthernet
MODBUS-GW
FACP FACP
IP Network
MODBUS-GW
FACP
Modbus/IP Client
HS-NCM
or
NCM
NFN Network
Ethernet Ethernet
Ethernet
MODBUS-GW
Configuration Web
Page
