MODBUS-GW Installation and Operation Manual — P/N LS10015-000NF-E:C2 4/30/2019 47
Device Types
FIRE CONTROL 77 MASS NOTIFICATION TROUBLE MON 105
HAZARD ALERT 78 MASS NOTIFICATION MONITOR 106
Table D.3 Device Type Values – Control Modules
DEVICE TYPE Value DEVICE TYPE Value
CONTROL 151 ALARMS PEND 168
RELAY 152 CONTROL NAC 169
BELL CIRCUIT 153 GEN ALARM 170
STROBE CKT 154 GEN SUPERVIS 171
HORN CIRCUIT 155 GEN TROUBLE 172
AUDIBLE CKT 156 GENERAL PEND 173
SPEAKER 157 TROUBLE PEND 174
REL END BELL 158 FORM C RESET 175
(blank) 159 ISOLATED SPK 176
RELEASE CKT 160 ISOLATED NAC 177
REL CKT ULC 161 RELAY FDBACK 178
RELEA.FORM C 162 REL FORM C FB 179
REL AUDIBLE 163 MASS NOTIFICATION GENERAL 180
NONRESET CTL 164 MASS NOTIFICATION CONTROL 181
TELEPHONE 165 MASS NOTIFICATION STROBE 182
REL CODE BELL 166 MASS NOTIFICATION SPEAKER 183
INSTANT RELE 167 MASS NOTIFICATION RELAY 184
Table D.2 Device Type Values – Monitor Modules (Continued)
DEVICE TYPE Value DEVICE TYPE Value
