MODBUS-GW Installation and Operation Manual — P/N LS10015-000NF-E:C2 4/30/2019 35
Zones/Panel Circuits Status Holding Registers Register Mapping
The holding register addresses and the panel circuits contained in these addresses are detailed in Table 5.7.
Table 5.7 Panel Circuits
The maximum panel circuit points by fire panel is described in Table 5.8.
Register Address Panel Circuits
49111–49118 P1.1–P1.8
49119–49126 P2.1–P2.8
49127–49134 P3.1–P3.8
49135–49142 P4.1–P4.8
49143–49150 P5.1–P5.8
49151–49158 P6.1–P6.8
49159–49166 P7.1–P7.8
49167–49174 P8.1–P8.8
49175–49182 P9.1–P9.8
49183–49190 P10.1–P10.8
49191–49198 P11.1–P11.8
49199–49206 P12.1– P12.8
Table 5.8 Supported Circuits by Panel
Panel Max. Panel Circuits Points
NFS-320 Not Supported
NFS-640 8
NFS2-640 Not Supported
NFS-3030 12
NFS2-3030 Not Supported
