48 MODBUS-GW Installation and Operation Manual — P/N LS10015-000NF-E:C2 4/30/2019
Appendix E System Troubles
Table E.1 System Troubles Register Map
Register Bit No. System Trouble Name Bit No. System Trouble Name
35001
0 GROUND FAULT 8 INTERNAL RAM ERROR
1 AC FAIL 9 EXTERNAL RAM ERROR
2 BATTERY 10 PROGRAM CORRUPTED
3 STYLE 6 POS. LOOP 1 11 NO DEV. INST ON L1
4 STYLE 6 POS. LOOP 2 12 PANEL DOOR OPEN
5 CORRUPT LOGIC EQUAT 13 AUXILIARY TROUBLE
6 LCD80 SUPERVISORY 14 TERM. SUPERVISORY
7 EPROM ERROR 15 ANNUN. 1 TROUBLE
35002 0 ANNUN. 1 NO ANSWER 8 ANNUN. 5 NO ANSWER
1 ANNUN. 2 TROUBLE 9 ANNUN. 6 TROUBLE
2 ANNUN. 2 NO ANSWER 10 ANNUN. 6 NO ANSWER
3 ANNUN. 3 TROUBLE 11 ANNUN. 7 TROUBLE
4 ANNUN. 3 NO ANSWER 12 ANNUN. 7 NO ANSWER
5 ANNUN. 4 TROUBLE 13 ANNUN. 8 TROUBLE
6 ANNUN. 4 NO ANSWER 14 ANNUN. 8 NO ANSWER
7 ANNUN. 5 TROUBLE 15 ANNUN. 9 TROUBLE
35003
0 ANNUN. 9 NO ANSWER 8 ANNUN.13 NO ANSWER
1 ANNUN.10 TROUBLE 9 ANNUN.14 TROUBLE
2 ANNUN.10 NO ANSWER 10 ANNUN.14 NO ANSWER
3 ANNUN.11 TROUBLE 11 ANNUN.15 TROUBLE
4 ANNUN.11 NO ANSWER 12 ANNUN.15 NO ANSWER
5 ANNUN.12 TROUBLE 13 ANNUN.16 TROUBLE
6 ANNUN.12 NO ANSWER 14 ANNUN.16 NO ANSWER
7 ANNUN.13 TROUBLE 15 ANNUN.17 TROUBLE
35004
0 ANNUN.17 NO ANSWER 8 ANNUN.21 NO ANSWER
1 ANNUN.18 TROUBLE 9 ANNUN.22 TROUBLE
2 ANNUN.18 NO ANSWER 10 ANNUN.22 NO ANSWER
3 ANNUN.19 TROUBLE 11 ANNUN.23 TROUBLE
4 ANNUN.19 NO ANSWER 12 ANNUN.23 NO ANSWER
5 ANNUN.20 TROUBLE 13 ANNUN.24 TROUBLE
6 ANNUN.20 NO ANSWER 14 ANNUN.24 NO ANSWER
7 ANNUN.21 TROUBLE 15 ANNUN.25 TROUBLE
35005
0 ANNUN.25 NO ANSWER 8 ANNUN.29 NO ANSWER
1 ANNUN.26 TROUBLE 9 ANNUN.30 TROUBLE
2 ANNUN.26 NO ANSWER 10 ANNUN.30 NO ANSWER
3 ANNUN.27 TROUBLE 11 ANNUN.31 TROUBLE
4 ANNUN.27 NO ANSWER 12 ANNUN.31 NO ANSWER
5 ANNUN.28 TROUBLE 13 ANNUN.32 TROUBLE
6 ANNUN.28 NO ANSWER 14 ANNUN.32 NO ANSWER
7 ANNUN.29 TROUBLE 15 NETWORK FAIL PORT A
To Next Page
