NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14 43
Basic Program Programming
ACS Selection Group Q (SLC #2, Modules 65-100 and Detectors 1-14):
Table 2.28 ACS Group Q (see note 3)
Point Type Red LED Yellow LED Switch Function*
1 Input SLC 2, Module 65 Alarm SLC 2, Module 65 Trouble Not Used
2 Input SLC 2, Module 66 Alarm SLC 2, Module 66 Trouble Not Used
3 Input SLC 2, Module 67 Alarm SLC 2, Module 67 Trouble Not Used
to to (see note 1) to (see note 1)
36 Input SLC 2, Module 100 Alarm SLC 2, Module 100
Trouble
Not Used
37 Input SLC 2, Detector 1 Alarm SLC 2, Detector 1 Trouble Not Used
38 Input SLC 2, Detector 1 Trouble
Maintenance Urgent
SLC 2, Detector 1 Trouble
Maintenance Alert
Not Used
39 Input SLC 2, Detector 2 Alarm SLC 2, Detector 2 Trouble Not Used
40 Input SLC 2, Detector 2 Trouble
Maintenance Urgent
SLC 2, Detector 2 Trouble
Maintenance Alert
Not Used
to (see note 2) to (see note 2)
63 Input SLC 2, Detector 14 Alarm SLC 2, Detector 14
Trouble
Not Used
64 Input SLC 2, Detector 14
Trouble Maintenance
Urgent
SLC 2, Detector 14
Trouble Maintenance Alert
Not Used
* Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to stop
blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.
NOTE:
1. Point number to Module number relationship is sequential. To determine Point to Module
relationship add 64 to Point number to arrive at Module number.
2. Point number to Detector number relationship is sequential in groups of 2. Since each detector
occupies 2 points, to determine the Point to Detector relationship, count by 2 starting from point
37.
3. This group is only available when UDACT setting is programmed as option 2 and will
automatically be assigned to ACS address 25.
