ACS Selection Group R (SLC #1, Detectors 15-46):
ACS Selection Group S (SLC #2, Detectors 15-46):
Table 2.29 ACS Group R
Point Type Red LED Yellow LED Switch Function*
1 Input Detector 015 Alarm Detector 015 Trouble Not Used
2 Input Detector 015 Trouble
Maintenance Urgent
Detector 015 Trouble
Maintenance Alert
Not Used
3 Input Detector 016 Alarm Detector 016 Trouble Not Used
4 Input Detector 016 Trouble
Maintenance Urgent
Detector 016 Trouble
Maintenance Alert
Not Used
to to (see note 1) to (see note 1)
63 Input Detector 046 Alarm Detector 046 Trouble Not Used
64 Input Detector 046 trouble
Maintenance Urgent
Detector 046 Trouble
Maintenance Alert
Not Used
* Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to
stop blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.
NOTE:
1.Point number to Detector number relationship is sequential in groups of 2. Since each detector
occupies 2 points, to determine the Point to Detector relationship, start with detector 15 and count
by 2 starting from point 1.
2. This group is only available when UDACT setting is programmed as option 2 and will
automatically be assigned to ACS address 26.
Table 2.30 ACS Group S
Point Type Red LED Yellow LED Switch Function*
1 Input Detector 015 Alarm Detector 015 Trouble Not Used
2 Input Detector 015 Trouble
Maintenance Urgent
Detector 015 Trouble
Maintenance Alert
Not Used
3 Input Detector 016 Alarm Detector 016 Trouble Not Used
4 Input Detector 016 Trouble
Maintenance Urgent
Detector 016 Trouble
Maintenance Alert
Not Used
to to (see note 1) to (see note 1)
63 Input Detector 046 Alarm Detector 046 Trouble Not Used
64 Input Detector 046 Trouble
Maintenance Urgent
Detector 046 Trouble
Maintenance Alert
Not Used
* Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to
stop blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.
NOTE:
1. Point number to Detector number relationship is sequential in groups of 2. Since each detector
occupies 2 points, to determine the Point to Detector relationship, start with detector 15 and count
by 2 starting from point 1.
2. This group is only available when UDACT setting is programmed as option 2 and will
automatically be assigned to ACS address 27.
