NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14 45
Basic Program Programming
ACS Selection Group T (SLC #1, Detectors 47-78):
ACS Selection Group U (SLC #2, Detectors 47-78):
Table 2.31 ACS Group T
Point Type Red LED Yellow LED Switch Function*
1 Input Detector 047 Alarm Detector 047 Trouble Not Used
2 Input Detector 047 trouble
Maintenance Urgent
Detector 047 Trouble
Maintenance Alert
Not Used
3 Input Detector 048 Alarm Detector 048 Trouble Not Used
4 Input Detector 048 Trouble
Maintenance Urgent
Detector 048 Trouble
Maintenance Alert
Not Used
to to (see note 1) to (see note 1)
63 Input Detector 078 Alarm Detector 078 Trouble Not Used
64 Input Detector 078 Trouble
Maintenance Urgent
Detector 078 Trouble
Maintenance Alert
Not Used
* Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to
stop blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.
NOTE:
1. Point number to Detector number relationship is sequential in groups of 2. Since each detector
occupies 2 points, to determine the Point to Detector relationship, start with detector 47 and count
by 2 starting from point 1.
2. This group is only available when UDACT setting is programmed as option 2 and will
automatically be assigned to ACS address 28.
Table 2.32 ACS Group U
Point Type Red LED Yellow LED Switch Function*
1 Input Detector 047 Alarm Detector 047 Trouble Not Used
2 Input Detector 047 Trouble
Maintenance Urgent
Detector 047 Trouble
Maintenance Alert
Not Used
3 Input Detector 048 Alarm Detector 048 Trouble Not Used
4 Input Detector 048 Trouble
Maintenance Urgent
Detector 048 Trouble
Maintenance Alert
Not Used
to to (see note 1) to (see note 1)
63 Input Detector 078 Alarm Detector 078 Trouble Not Used
64 Input Detector 078 Trouble
Maintenance Urgent
Detector 078 Trouble
Maintenance Alert
Not Used
* Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to
stop blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.
NOTE:
1. Point number to Detector number relationship is sequential in groups of 2. Since each detector
occupies 2 points, to determine the Point to Detector relationship, start with detector 47 and count
by 2 starting from point 1.
2. This group is only available when UDACT setting is programmed as option 2 and will
automatically be assigned to ACS address 29.
