39Chapter 6 Electrical Installation
Searchline Excel™ Plus / Searchline Excel™ Edge – Technical Manual
6.3.2Transmitter Connections / Wiring diagram
Ø=78 mm
NOTES:
1.MATERIAL:
LABEL:2331D0238
INKRIBBON:BRADYR6000THERMALTRANSFERPRINTED-BLACK.
2.THISPRODUCTMUSTBERoHSCOMPLIANT
3.VALUESSHOWNONARETYPICALANDAREFORINFORMATIONPURPOSESONLY.PRODUCTDATAISENTEREDBYTHEPRODUCTIONCONFIGURATIONSYSTEM
2017Dxxxx
THISDOCUMENTHASBEENGENERATEDUSINGINDESIGN
ANDMUSTONLYBEUPDATEDBYINDESIGN
FINISH
N/A
MATERIAL
SEENOTE1
SCALE
1:1
1 ISSUE
14/05/20
DATE
A05398
CHANGE
KSM
ACTIONEDBY
DRAWNK.SMRCEK DATE19-Feb-20
TITLE
SEARCHLINEEXCELTx
INNERREARCOVERLABEL
2017Dxxxx
SHT.1
OF1
©2020LIFESAFETYDISTRIBUTION
GmbH.
ALLRIGHTSRESERVED.
THISDOCUMENTCONTAINSPROPRIETARY
INFORMATIONOFLIFESAFETY
DISTRIBUTIONGmbHANDITSAFFILIATED
COMPANIESANDISPROTECTEDBY
COPYRIGHTANDOTHERINTERNATIONAL
LAWS.REPRODUCTIONORIMPROPER
USEWITHOUTSPECIFICAUTHORIZATION
OFLIFESAFETYDISTRIBUTIONGmbHIS
STRICTLYFORBIDDEN.
TOLERANCESTOBEASSPECIFIED
BELOWUNLESSOTHERWISESTATED.
DIMS.2DP±0.1mm
1DP±0.25mm
NONE±0.4mm
ANGULAR±1/2°
HOLESØ0to8
+0.08
-0.0
Ø8to14
+0.1
-0.0
Ø14to25
+0.12
-0.0
UNLESSOTHERWISESTATED:
ALLDIMENSIONSINMILLIMETRESTO
APPLYAFTERPLATING.
ALLTHREADSTOBEBS3643.
REMOVEALLBURRSANDSHARPEDGES.
SURFACETEXTUREVALUESAREINm
RaANDTOBS 1134.
THISDRAWINGISTOBS8888.
A3
10 0V DC
9 0V DC
8 24V DC
7 24V DC
6 N/A
5 N/A
4 N/A
3 N/A
2 N/A
1 N/A
11 N/A
12 N/A
13 N/A
14 N/A
15 N/A
16 N/A
17 N/A
18 N/A
19 N/A
20 N/A
21 N/A
QR CodeQR Code
Registration
Serial Number:
Z123456789012
Activation Key:
ABCDEFGHIJKLMNOP
THISITEMFORMSPARTOFACERTIFIEDPRODUCT.NO
MODIFICATIONPERMITTEDWITHOUTREFERENCETOCERTIFYING
AUTHORITY
Figure 28.Transmitter Terminal Connector Label
TRANSMITTER
CONNECTIONS
EXTERNAL
POWER
SUPPLY
+24 Vdc
0 Vdc
Figure 29.Transmitter Connections
Note
The transmitter is immune against accidental reverse polarity connection of power. Refer to Section 6.3.5 Transmitter with
LED Indicator Disabled.
Note:
Wiring must be done in accordance with local, national and/or company regulations. Exposed, bare conductors must be
avoided.
6.3.3LED Indicator Switch Off
For installations where LED Indicator operation is not required, the LED Indicator can be switched off by reversing polarity
of the power supply wiring. This will only disable the LED Indicator, other transmitter functions will not be affected.
