56 Chapter 8 Operation and Configuration
Searchline Excel™ Plus / Searchline Excel™ Edge – Technical Manual
Parameter Name Description
Gas Reading Final gas reading expressed as in Gas Reading Units.
Range depends on unit and gas type selection.
Access: R
Gas Type Gas type configured in factory.
1 – UNIVERSAL HYDROCARBON (default)
2 – METHANE,
3 – ETHANE,
4 – PROPANE,
5 – BUTANE,
6 – PENTANE,
7 – ETHYLENE,
8 – PROPYLENE,
Access: R
Path Length Distance between transmitter and receiver in meters.
units – meters
range:
Searchline Excel Plus: 2~120 m (6 ft to 393 ft)
Searchline Excel Edge: 60~330 m (196 ft to 1082 ft)
Access: R/W
Filter Level level of filtration that affects response time
level 0 = 3 pulses (response time 1s)
level 1 = 7 pulses (response time 2s)
level 2 = 11 pulses (response time 3s)
Access: R/W
Dynamic Reserve Dynamic reserve of the reference signal
Range 0.0~1.0
0 – no reserve
1 – full range
Access: R
System Type Identification of device type.
1 – Searchline Excel Plus)
2 – Searchline Excel Edge)
Access: R
AutoZeroEnable Enables floating baseline control (automatic runtime
calibration)
0 – disabled
1 – enabled
Access: R/W
Alignment Status Tx Status of transmitter optical alignment.
0 – OK
1 – misaligned
Access: R
Alignment Status Rx Status of receiver optical alignment.
0 – OK
1 – misaligned
Access: R
Alignment Status Disconnected – Transmitter alignment is being detected
Connecting – Transmitter alignment is being detected
Connected – Transmitter alignment is detected
Access: R
Zero Calibration Result Zero value means device is correctly calibrated.
Non-zero value means potential issue with calibration (bit 8
has failed).
Access: R
