93Chapter 14 Specifications
Searchline Excel™ Plus / Searchline Excel™ Edge – Technical Manual
Specifications
Power Consumption
(average RMS)
Transmitter, for ambient operating temperature:
55°C (67°F) to 30°C (22°F) 11.8 W
30°C (22°F) to +30°C (+86°F) 5.6 W
above +30°C (+86°F) 3.8 W
Receiver, for ambient operating temperature:
55°C (67°F) to 30°C (22°F) 7.4 W
30°C (22°F) to +30°C (+86°F) 4.8 W
above +30°C (+86°F) 3.0 W
See Electrical Installation of this manual for full details.
Cold Start / Heat-up
Power Consumption
Heat-up last approx. 20 min for both Transmitter and Receiver
Transmitter: 17 W
Receiver: 10 W for ambient operating temperature higher than 30 °C (22 °F)
15 W for ambient operating temperature lower than 30 °C (22 °F) (active heater)
Output Signals 4–20 mA with HART, Fault relay, Alarm 1 relay, Alarm 2 relay, Modbus, Bluetooth® (range up to
20 m (66 ft), depends on mobile device and environmental conditions)
Relay Outputs Max. 32 Vdc/ac, max. 2 A resistive load
Inrush Current Transmitter: 0.5 A for less than 20 ms
Receiver: 0.3 A for less than 20 ms
Humidity 0–99 % RH Non-condensing, DNVGLCG0339 Location Class B
Pressure 91.5–105.5 kPa (915–1055 mBar, non-compensated)
Repeatability
±0.4 LEL.m:
Methane ±17,600 ppm.m
Ethane ±9,600 ppm.m
Propane ±6,800 ppm.m
Butane ±5,600 ppm.m
Pentane ±4,400 ppm.m
Hexane ±4,000 ppm.m
Ethylene ±9,200 ppm.m
Propylene ±8,000 ppm.m
Temperature Drift
(55 °C to +75 °C)
(67 °F to +167 °F)
±0.2 LEL.m @ zero: ±0.5 LEL.m @ 3LEL.m:
Methane ±8,800 ppm.m Methane ±22,000 ppm.m @ 132,000 ppm.m
Ethane ±4,800 ppm.m Ethane ±12,000 ppm.m @ 72,000 ppm.m
Propane ±3,400 ppm.m Propane ±8,500 ppm.m @ 51,000 ppm.m
Butane ±2,800 ppm.m Butane ±7,000 ppm.m @ 42,000 ppm.m
Pentane ±2,200 ppm.m Pentane ±5,500 ppm.m @ 33,000 ppm.m
Hexane ±2,000 ppm.m Hexane ±5.000 ppm.m @ 30,000 ppm.m
Ethylene ±4,600 ppm.m Ethylene ±11.500 ppm.m @ 69,000 ppm.m
Propylene ±4,000 ppm.m Propylene ±10.000 ppm.m @ 60,000 ppm.m
Warm-up Time Less than 5 minutes (operational), less than 1 hour (fully stabilised)
Internal Battery Cell TLH2450, 10-year lifetime (replaced only by authorized service)
Weight Searchline Excel Plus and Searchline Excel Edge: Rx 6.1 kg (13.4 lbs), Tx 6.0 kg (13.2 lbs)
Universal Mounting Bracket: 3.1 kg (6.9 lbs) Stainless Steel
Mount Plate Adaptor: 3.71 kg (8.18 lbs) Stainless Steel
Dimensions Searchline Excel Plus and Searchline Excel Edge: 103 mm dia x 325 mm x 180 mm (4.06" dia x
12.8" x 7.09")
Universal Mounting Bracket: 165 mm x 165 mm x 130 mm (6.5" x 6.5” x 5.12")
Mount Plate Adaptor: 210 mm x 210 mm x 127 mm (8.23" x 8.23” x 5")
Ingress Protection IP 66/67 (Type 4X, in accordance with NEMA 250)
1, 2
1
IP and/or corrosion resistance ratings refer to the instrument enclosure protection. They do
not imply that the instrument will detect gas during and immediately after exposure to those
conditions
2
Refer to Ch.9 Maintenance for recommendations and maintenance requirements regarding
deluge and flooding
Resistance to salt mist and sulphuric atmosphere (1560 minutes exposure to salt air/mist;
15–60 minutes to sulphuric atmosphere)
