1/99 SMV 3000 Transmitter User’s Manual 93
8.2 Accessing Operation Data, Continued
Procedure, continued
Table 25 Accessing Transmitter Operation Data Using SCT,
Continued
IF you want to view… Select the SCT
Window or Tab Card
And . . .
1. the input value for a
given PV, which is
updated every six
seconds.
2.
the present transmitter
output in percent for a
given PV, which is
updated every six
seconds.
PV Monitor Window Read: PV Input
PV % of span
1. the span, which is the
URV minus the LRV for
a given PV.
2.
the Upper Range Limit
of a given PV.
3.
the Lower Range Limit
of a given PV.
DPConf (for PV1)
APConf (for PV2)
TempConf (for PV3)
FlowConf (for PV4)
Read: Span
URL
LRL
the failsafe output direction
for the transmitter.
ATTENTION
You can
change the default failsafe
direction from upscale to
downscale. See Section 8.3,
“Changing Default Failsafe
Direction”.
General Tab Card Read:
Analog Failsafe
Direction
the present meter body
temperature (±5 °C)
measured by circuitry in the
transmitter’s sensor.
ATTENTION
You can
change the temperature
engineering units to °F, °R
or °K by selecting the SV
Units field in the DPConf tab
card.
PV Monitor Window
Click on SV button on
DP gauge
Read: SV
Continued on next page
