144 SMV 3000 Transmitter User’s Manual 1/99
12.1 Replacement Parts, Continued
Table 38 Parts Identification for Callouts in Figure 32, Continued
Key
No.
Part Number Description Quantity
Per Unit
30753787-001 Monel vent/drain and plug kit
K3
Pipe plug 4
K4
Vent plug 2
K5
Vent bushing 2
30753786-001 Hastelloy C vent/drain and plug kit
K3
Pipe plug 4
K4
Vent plug 2
K5
Vent bushing 2
30753788-003† Process head gasket kit (PTFE material)
30753788-004† Process head gasket kit (Viton material)
K7
Gasket [for gasket only: 30756445-501 (PTFE) or 30749274-501 (Viton)] 6
K8
O-ring 3
K9
Seal 3
K10
Gasket, flange adapter (for gasket only: 30679622-501) 6
K14
30757503-001 Enclosure seals 2
Flange Adapter Kits (two heads)
30754419-002 Flange adapter kit (st. steel flange adapters with carbon steel bolts)
30754419-004 Flange adapter kit (monel flange adapters with carbon steel bolts)
30754419-018 Flange adapter kit (st. steel flange adapters with 316 st. steel bolts)
30754419-020 Flange adapter kit (monel flange adapters with 316 st. steel bolts)
K1
Bolt, hex head, 7/16-20 UNF, 1.375 inches lg., flange adapter 4
K10
Gasket, flange adapter 2
K11
Flange adapter 2
K12
Filter screen 2
30754419-003 Flange adapter kit (hastelloy C flange adapters with carbon steel bolts)
30754419-019 Flange adapter kit (hastelloy C flange adapters with 316 st. steel bolts)
K1
Bolt, hex head, 7/16-20 UNF, 1.375 inches lg., flange adapter 4
K10
Gasket, flange adapter 2
K11
Flange adapter 2
Continued on next page
