16 SMV 3000 Transmitter User’s Manual 1/99
3.2 Considerations for SMV 3000 Transmitter, Continued
RTD requirements
Use a two-, three-, or four-wire platinum 100 ohm (Pt100) Resistance
Temperature Detector with rated measurement range limits of –200 to
450 °C (–328 to 842 °F) per DIN 43760 standard (α = 0.00385 Ω/Ω/°C)
as the input source for the process temperature PV.
Thermocouple
requirements
Use one of the thermocouple types listed in Table 4 as the input source for
the process temperature.
Table 4 Thermocouple Types for Process Temperature Sensor
Type Rated Range Limits Standard
°C °F
E
0 to 1000 32 to 1832 IEC584.1
J
0 to 1200 32 to 2192 IEC584.1
K
–100 to 1250 –148 to 2282 IEC584.1
T
–100 to 400 –148 to 752 IEC584.1
