1/99 SMV 3000 Transmitter User’s Manual 137
Section 12 Parts List
12.1 Replacement Parts
Part Identification
• All individually salable parts are indicated in each figure by key number
callout. For example, 1, 2, 3, and so on.
• All parts that are supplied in kits are indicated in each Figure by key
number callout with the letter “K” prefix. For example, K1, K2, K3,
and so on.
• Parts denoted with a “†” are recommended spares. See Table 39 for
summary list of recommended spare parts.
Figure 29 shows major parts for given model with parts list Figure
reference
Continued on next page
