Section 6 Configuration
6.1 Introduction
Section Contents
This section includes these topics
Topic See Page
6.1 Introduction ............................................................................45
6.2 Overview................................................................................47
6.3 Configuring the SMV 3000 with The SCT...............................49
6.4 Device Configuration ............................................................50
6.5 General Configuration ..........................................................51
6.6 DPConf Configuration - PV1.................................................54
6.7 AP/GPConf Configuration - PV2...........................................59
6.8 TempConf Configuration - PV3 ............................................61
6.9 FlowConf Configuration - PV4..............................................68
6.10 Flow Compensation Wizard....................................................74
6.11 Using Custom Engineering Units............................................75
6.12 Saving, Downloading and Printing a Configuration
File.........................................................................................77
6.13 Verifying Flow Configuration ..................................................78
About This Section
This section introduces you to SMV 3000 transmitter configuration. It
identifies the parameters that make up the transmitter’s configuration
database and provides information for entering values/selections for the
given configuration parameters using the SCT.
