SMV 3000 Transmitter User’s Manual 1/99164
A.6 Operation Notes
Generic Operations
Most operator actions initiated through Detail displays at the Universal
Station are generic for all Smartline transmitters. Refer to Section 7 in the
PM/APM Smartline Transmitter Integration Manual for details about
these generic operations.
This section outlines some differences in operations that are unique to the
multivariable STIMV IOP and the SMV 3000 transmitter in particular.
Detail Display
Difference
Page 2 of the Detail display for a multivariable STIM point includes an
additional field in the lower right hand corner for PV Number and Number
of PVs identification as shown in Figure A-6. This lets you quickly
identify what PV number you are viewing and how many PVs are
associated with this given SMV 3000 transmitter.
Figure A-6 Detail Display with PV Number and Number of PVs Field.
F101 SMV SLOT 1 - DIFF PRESS 03 UNIT 01
CONFIG PAGE
PVFORMAT 01
PVSRCOPT ALL
PVCLAMP CLAMP
PVALDR ONE
PVALDEBEU 2.0000
INPTDIR REVERSE
LOCUTOFF -------
_________________ CONFIGURATION DATA ________________
PVCHAR LINEAR
SENSRTYP SPT_DP
PIUOTDCF OFF
BADPVPR LOW
PVHHPR NOACTION
PVHIPR NOACTION
PVLLPR NOACTION
PVLOPR NOACTION
PVROCPPR NOACTION
PVROCNPR NOACTION
______________ SMART TRANSMITTER DATA ______________
STITAG FT3011
SENSRTYP SPT_DP
PVCHAR LINEAR
CJTACT OFF
PIUOTDCF OFF
DECONF Pv_Sv_Db
PVRAW 50.000
URL 400.000
URV 250.000
LRV 0.00000
LUL 0.00000
STI_EU INH2O
SECVAR 21.5762
DAMPING 0.00000
SERIALNO 10775120
STISWVER 2.5
STATE OK
COMMAND NONE
TRANSMITTER SCRATCH PAD:
TRANSMITTER STATUS :
1 OF 1
23 Jun 98 11:15:23 6
PV Number
Number of PVs
Database Mismatch
Parameters
The following parameters are added to the list of parameters that the
STIMV IOP checks for database mismatches between itself and the
transmitter.
• PV Number
• Number of PVs
Continued on next page
