1/99 SMV 3000 Transmitter User’s Manual 29
4.4 Installing RTD or Thermocouple
Considerations
You are responsible for installing the thermowell to house the RTD or
thermocouple sensor. Be sure to use a spring-load accessory to hold the
RTD sensor against the end of the thermowell.
To reduce the effects of “noise,” use shielded cable or run sensor leads in
a conduit.
See the Guide to Temperature Sensors and Thermowells, 34-44-29-01
which tells you how to properly specify thermal probes and thermowell
assemblies for your application. Model selection guides also are included
for various temperature probes.
CE Conformity
Special Conditions
(Europe)
You must use shielded cable to connect sensor to transmitter’s
temperature circuit.
