122 SMV 3000 Transmitter User’s Manual 1/99
11.4 Diagnostic Messages
Diagnostic Messages
The diagnostic text messages that can be displayed on the SCT, SFC or on
a TPS/TDC system are listed in the following tables. A description of the
probable cause and suggested action to be taken are listed also to help in
troubleshooting error conditions.
The messages are grouped in tables according to the status message
categories.
Table 31 lists Critical status diagnostic messages
Table 32 - Non-critical status messages
Table 33 - Communications status messages
Table 34- Informational status messages
Table 35- SFC Diagnostic messages
Diagnostic Message
Table Headings
SMV Status column provides the location of the SMV status. If you are
using one of the diagnostic tools (SCT, SFC or Universal Station) that
contains an earlier software version, you may see the diagnostic messages
displayed as these SMV Status numbers.
The SCT Status Message column shows the text which appears in the
Status tab window when the SCT is in the on-line mode and connected to
the SMV control loop.
The SFC Display Message column shows the text which appears when
the SFC is connected to the SMV control loop and the [STAT] key is
pressed.
TDC Display Status Message column shows the text which appears on a
TPS/TDC Universal Station.
Some messages and information in the tables are specific to the SCT or
SFC and are noted.
Continued on next page
