1/99 SMV 3000 Transmitter User’s Manual 9
1.6 Transmitter Order
Order Components
Figure 6 shows the components that would be shipped and received for a
typical SMV 3000 transmitter order.
Figure 6 Typical SMV 3000 Transmitter Order Components
Mounting Bracket (Optional)
SMV 3000
w SMV 3000 Transmitter with optional mounting bracket
Ordered
Shipped
Received
User’s
Manual
ATTENTION
Honeywell can also supply the RTD or Thermocouple for use with an
SMV 3000. See “About Documentation,” next.
Continued on next page
