8 SMV 3000 Transmitter User’s Manual 1/99
1.5 Smart Field Communicator (SFC), Continued
Using the SFC with
the SMV 3000,
continued
• Change Mode
of Operation: Tell transmitter to operate in either its analog (4-20
mA) mode or its digital enhanced (DE) mode.
• Check Current
Output: Use the transmitter to supply the output current desired
for verifying analog loop operation, troubleshooting, or
calibrating other components in the analog loop.
• Simulate
Input: Use the transmitter to simulate a desired input value for
the selected PV for verifying transmitter operation.
• Troubleshoot: Check status of transmitter operation and display
diagnostic messages to identify transmitter,
communication, or operator error problems.
ATTENTION
For more information about using the SFC with the SMV 3000, see the
Smart Field Communicator Model STS103 Operating Guide,
34-ST-11-14. The document provides complete keystroke actions and
prompt displays.
Continued on next page
