1/99 SMV 3000 Transmitter User’s Manual 141
12.1 Replacement Parts, Continued
Table 36 Parts Identification for Callouts in Figure 30, Continued
Key
No.
Part Number Description Quantity
Per Kit
30753392-001† Accessory O-ring kit
K2
O-ring housing 6
30753783-001 Lock assembly kit, electronics terminal or meter cap (PTB)
K5
Lockwasher, metric, M4 12
K6
Lock, cover 12
K10
Flat washer, metric, M4 12
K11
Screw, socket head, metric, M4, 20 mm long 12
30753783-001 Lock assembly kit, electronics cap
K5
Lockwasher, metric, M4 12
K9
Lock, cover 6
K10
Flat washer, metric, M4 6
K11
Screw, socket head, metric, M4, 20 mm long 6
30753804-001 Ground terminal assembly kit
K3
Terminal strip, grounding 3
K4
Screw, pan head, metric, M4, 6 mm long 6
K5
Lockwasher, metric, M4 12
K7
Terminal, external 6
K8
Screw, pan head, metric, M4, 10 mm long 6
K14
Terminal washer (Not Shown) 3
30753784-001 Miscellaneous hardware kit
K1
Tapping screw, number 4, 4.75 mm lg 24
K4
Screw, pan head, metric, M4, 6 mm long 24
K5
Lockwasher, metric, M4 12
K12
Pipe plug, socket type 6
K13
Set screw, metric, M8, 18 mm long 6
Continued on next page
