SMV 3000 Transmitter User’s Manual 1/99174
Appendix B– Configuration Record Sheet, Continued
2c. General Flow Configuration Section
PV4 Range:
LRV ________ URV ________ URL ________
(defaults are
0, 100,000 and 100,000
m3/hr
)
PV4 Eng. Units:
cc/h ___ cc/min ___ l/h ___ l/min ___
(Volumetric Flow) gal/day ___ Kgal/day ___ gal/h ___ gal/min ___
bbl/day ___ m3/day ___
m3/hr ___
m3/min ___
m3/sec ___ CFM ___ CFH ___
Type of Volumetric Flow Units:
Standard Volume Units ____ Actual Volume Units ____
PV4 Eng. Units:
lb/min ___ lb/h ___ lb/sec ___ ton/sec ___
(Mass Flow) ton/min ___ ton/h ___ kg/min ___ kg/sec ___
kg/h ___ t/min ___
t/h ___
t/sec ___
g/sec ___ g/min ___ g/h ___
PV4 Eng. Units:
____ ____ ____ ____ ____ ____ ____ ____
= ______________
(Complete if choosing Custom Units, 8 characters Max.)
PV4 Damping (sec.): 0.0 ___
0.5 ___ 1.0 ___ 2.0 ___ 3.0 ___ 4.0 ___
5.0 ___ 10 ___ 50 ___ 100 ___
PV4 Low Flow Cutoff:
Low Limit ________ High Limit ________
(defaults are zero)
PV4 Failsafe: PV2 Failsafe On ___ PV2 Failsafe Off ___ Pressure ________
PV3 Failsafe On ___
PV3 Failsafe Off ___
Temperature _______
Configured By: ___________________________ Date: ___/___/___
Custom Fluids -
Liquid Applications - If you are using a custom fluid that is not listed in the SCT 3000 Flow Compensation Wizard, you
can supply values for density vs. temperature and viscosity vs. temperature in the flow equation (if dynamic
compensation is desired). If dynamic compensation is not desired, enter the density and viscosity values at normal
flowing conditions.
Density – lbs/ft
3
viscosity – cPoise temperature – deg. F
Gas and Steam Applications - If you are using a custom gas that is not listed in the SCT 3000 Flow Compensation
Wizard, you can supply values for viscosity vs. temperature in the flow equation (if dynamic viscosity is desired). If
dynamic compensation is not desired, enter the viscosity values at normal flowing conditions.
viscosity – cPoise temperature – deg. F
To Next Page
