1/99 SMV 3000 Transmitter User’s Manual 83
7.3 Running Output Check, Continued
Procedure
Table 20 Output Check for SMV Transmitters in DE Mode
Step Action
1
Connect SCT to SMV and establish communications. (See
Subsection 5.2 for procedure, if necessary.)
2
Be sure any switches that may trip alarms or interlocks associated
with analog loops are secured or turned off.
3
Perform Upload of the SMV database to the SCT.
4
Select General tab card and set communication mode to Digital
Enhanced.
5
Set any of the SMV transmitter PVs to output mode, by selecting the
appropriate tab cards.
• DPOutCal, (for PV1)
• APOutCal, (for PV2)
• TempOutCal, (for PV3) or
• FlowOutCal, (for PV4)
6
Enter an output value and then set PV to Output mode.
7
Open the PV Monitor window by selecting PV Monitor from the View
pull down menu. Read the PV outputs.
Also, check the PV outputs as displayed at the digital receiver.
8
Select appropriate tab card for the PVs that were set to output mode
and clear the output mode.
9
Select Status tab card to verify that all transmitter outputs are in not in
output mode and that there are no new messages.
