Honeywell TC300

Network outputs 43
no_ManualOverride Multistate
Value
2016 enum{Occupied=1,
Unoccupied=2,
Bypass=3,
Standby=4,
Null=5}
Manual override
no_EffOccSensState Multistate
Value
2017 enum{
Occupied=1,
UnOccupied=2,
Unused=3}
Effective occupancy sensor
state
no_CoolDaLolimit Binary
Value
2023 Normal=0,
LoLimit=1
Discharge air high limit
output: DAT cooling lockout
flag
no_CoolTermLdOut Analog
Value
2036 0 to 200% Terminal load for cooling
no_IsCoolDisable Binary
Value
2025 Enable=0,
Disable=1
Cooling enabled/ disabled.
no_HeatTermLdOut Analog
Value
2038 -200 to 0% Terminal load for heating
no_FanStart Binary
Value
2026 Off=0,
On=1
Fan start command
no_DaTemp Analog
Value
2040 -40 to 200 °F Discharge air temperature
no_PipeTemp Analog
Value
2041 -40 to 260 °F Pipe sensor temperature
no_EffSchCurrentState Multistate
Value
2018 enum{Occupied=1,
Unoccupied=2,
Bypass=3,
Standby=4,
NoOverride=5}
Current schedule state to
network.
no_EffSchNextState Multistate
Value
2019 enum{Occupied=1,
Unoccupied=2,
Bypass=3,
Standby=4,
NoOverride=5}
Next schedule state to
network.
no_EffTUNCOS Analog
Value
2042 0 to 11520 minutes TUNCOS is the difference
between the future change
in event & current event in
minutes to the network.
no_OverrideRemTime Analog
Value
2043 0 to 1080 minutes This point gives out the exact
remaining time for the
bypass to reset once the
system is in override
condition.
no_CtrlSpaceTemp Analog
Value
2044 -40 to 150 °F Control space temperature
output (Only for testing
purpose)
Table 10 Network outputs (Continued)
Name
BACnet
Object
Type
BACnet
Object
Instance
Range Description
