Honeywell TC300 User Manual

Equipment configuration 53
EQUIPMENT CONFIGURATION
4-Pipe Single Coil
2. Tap 4-Pipe Single Coil.
The 4-Pipe Single Coil screen appears.
Note: If Output is set to 0-10 Vdc
- Heating Rage: 0.0-4.7 Vdc
- Cooling Range: 5.3-10.0 Vdc
- Off voltage is 4.7-5.3Vdc
Table 20: 4-Pipe single coil
Valve type
Valve
operation/
Output
Options Description
Regulating and changeover On/Off Normally open Set Valve output type as N.C
Normally close Set Valve output type as N.O
Floating -
• Set output type Direct or Reverse
• Set output type Direct or Reverse
• Set Min position when enabled
• Enable sync at mid night
Modulating Modulating
control
• Min output when enabled
• Use Stage 1 cool as enabled
Modulating
setting
• Set output type Direct or Reverse
• Set Min output of Modulating
valve
• Set Max output of Modulating
valve
Changeover Energize on
heat
- Set Changeover relay type
Energize on
cool
- Set Changeover relay type
6-Way Valve 2-10V Cooling Range
• Configure Min Output for Cooling
• Configure Max Output for Cooling
• Tap the Info icon to view the
minimum allowed deadband
range
Heating Range
• Configure Min Output for Heating
• Configure Max Output for Heating
Reverse Exchange the heating range and
cooling range
0-10V Cooling Range
• Configure Min Output for Cooling
• Configure Max Output for Cooling
• Tap the Info icon to view the
minimum allowed deadband
range
Heating Range
• Configure Min Output for Heating
• Configure Max Output for Heating
Reverse Exchange the heating range and
cooling range
