HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
19 31-00610-01
UIO
52 IO1 Universal signal input / output 1
53 C Common
54 IO2 Universal signal input / output 2
55 IO3 Universal signal input / output 3
56 C Common
57 IO4 Universal signal input / output 4
58 IO5 Universal signal input / output 5
59 C Common
60 IO6 Universal signal input / output 6
61 IO7 Universal signal input / output 7
62 C Common
63 IO8 Universal signal input / output 8
64 C Common + 24 VDC
65 OUT Power Output + 24 VDC
66 IO9 Universal signal input / output 9
67 C Common
68 IO10 Universal signal input / output 10
69 IO11 Universal signal input / output 11
70 C Common
71 IO12 Universal signal input / output 12
BACnet
TM
RJ45 (IP) Model
Port 1 Port 1 Ethernet IP 1, 10/100 Switched
Port 2 Port 2 Ethernet IP 2, 10/100 Switched
BACnet
TM
MS/TP Model
42 +
BACnet
TM
MS/TP positive
43 -
BACnet
TM
MS/TP negative
44 SHLD
BACnet
TM
MS/TP shield
BACnet
TM
T1L Model
39 DA+ T1L Switch 1
40 DA- T1L Switch 1
41 T1L Switch 1 Common
42 DA+ T1L Switch 2
43 DA- T1L Switch 2
44 T1L Switch 2 Common
Table 15 Terminal Connections
Terminal Label Description

Honeywell Unitary Specifications

General

Brand	Honeywell
Model	Unitary
Category	Controller
Language	English
