HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
7 31-00610-01
T1L Communication
Supported Devices*
Weight and Dimensions
Universal IO*
* Devices subject to local availability. Contact your local
sales representative for information on available
devices in your region.
Table 7 T1L Specifications
Parameter Specification
10BASE-T1L
Standard
802.3cg-2019
Connection Screw terminal, auto MDI-X
Cable Type
Single twisted pair, 18AWG,
shielded or unshielded. Belden
74040NH, 9841NH or equivalent.
Cable compliance with standard
IEC 61156-13 or equivalent is
preferred.
Distance
Maximum 660 ft. (200 m) to
Honeywell T1L controller in daisy
chain. Maximum 2,950 ft.
(900 m) to any other T1L device
without a daisy
chain.
Transmission
Mode
10 Mbps
Table 8 Supported Devices
Parameter Specification
Sylk™ wall
Modules
TR42, TR42-H, TR42-CO2, TR42-H-
CO2, TR71, TR71-H, TR75, TR75-H,
TR75-HE, TR120 (TR75-E), and
TR120-H (emulation mode only).
Sylk™ sensor
TR40, TR40-H, TR40-CO2, TR40-H-
CO2, TR50, C7400S
Sylk™
Actuator
MS3103, MS3105, MS3110, and
MS3120
Non Sylk™
Actuators
M6410C2023, M6410C2031,
ML6420A3007, ML6420A3023,
MT4-024, and MT8-024
Hardwired
Wall Modules
TR21, TR22, TR23, TR24, T7460 A,
B, C, D, E, F and T7770 A, B, C, D, E,
F, G
Modbus
devices
Modbus RTU devices from any
manufacturer (including Honeywell
Modbus devices, for example
DALI64MODPSUF/S, TR50, and
TR80) can be used.
Table 9 Weight And Dimensions
Parameter Specification
Dimension
(L x W x H)
Large - 8.5 x 4.79 x 2.1 inches (216 x
121.6 x 53 mm).
Small - 7.1 x 4.7 x 2.1 inches (180 x
121.6 x 53 mm).
Weight
Large - 1.54 lbs. (700 grams)
Small - 1.32 lbs. (600 grams)
Mounting
Mounting in fuse boxes (DIN43880),
on DIN rails or surface mounted with
optional protection covers.
Table 10 Universal IO Specification
Parameter Specification
AI
16-bit A/D resolution
• 0 to 10 V or 0 to 20 mA input.
• Sensors: 10K Ohm NTC Type II, 10K
Ohm NTC Type III, 10K3A1, 20K Ohm
NTC, PT100, PT1000,
NI1000TK5000, NI1000 Class B
DIN43760, PT3000, 100 Ohm to
100K Ohm resistive (custom
characteristic).
• Hardwired wall modules*: space
temperature, space temperature set
point, fan speed override, occupancy
mode override.
BI
• Dry contact binary input with
direct/reverse.
• Pulse input with maximum
frequency 100 Hz, minimum pulse
width 5 ms. Compatible with the
S0* interface for pulse counters.
AO
• Voltage output 0 to 11 V with
25 mA (short circuit sourcing) and
3 mA (short circuit sinking).
• Current output with 0(4)…20 mA
direct/reverse.
• Hardwired wall modules*: LED
Control.
DO
0...10 VDC at 20 mA binary output with
direct/reverse.
