HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
31-00610-01 54
PT1000 Characteristics
Table 41 PT1000 Characteristics
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage
[V]
-58 -50 803 0.312 8.6 -13 949 0.367
-56.2 -49 807 0.314 10.4 -12 953 0.369
-54.4 -48 811 0.315 12.2 -11 957 0.37
-52.6 -47 815 0.317 14 -10 961 0.372
-50.8 -46 819 0.318 15.8 -9 965 0.373
-49 -45 823 0.32 17.6 -8 969 0.375
-47.2 -44 827 0.321 19.4 -7 973 0.376
-45.4 -43 831 0.323 21.2 -6 977 0.378
-43.6 -42 835 0.324 23 -5 980 0.379
-41.8 -41 839 0.326 24.8 -4 984 0.38
-40 -40 843 0.327 26.6 -3 988 0.382
-38.2 -39 847 0.329 28.4 -2 992 0.383
-36.4 -38 851 0.33 30.2 -1 996 0.385
-34.6 -37 855 0.332 32 0 1000 0.386
-32.8 -36 859 0.333 33.8 1 1004 0.388
-31 -35 862 0.335 35.6 2 1008 0.389
-29.2 -34 866 0.336 37.4 3 1012 0.391
-27.4 -33 870 0.338 39.2 4 1016 0.392
-25.6 -32 874 0.339 41 5 1020 0.394
-23.8 -31 878 0.341 42.8 6 1023 0.395
-22 -30 882 0.342 44.6 7 1027 0.396
-20.2 -29 886 0.344 46.4 8 1031 0.398
-18.4 -28 890 0.345 48.2 9 1035 0.399
-16.6 -27 894 0.347 50 10 1039 0.401
-14.8 -26 898 0.348 51.8 11 1043 0.402
-13 -25 902 0.35 53.6 12 1047 0.404
-11.2 -24 906 0.351 55.4 13 1051 0.405
-9.4 -23 910 0.353 57.2 14 1055 0.406
-7.6 -22 914 0.354 59 15 1058 0.408
-5.8 -21 918 0.356 60.8 16 1062 0.409
-4 -20 922 0.357 62.6 17 1066 0.411
-2.2 -19 926 0.359 64.4 18 1070 0.412
-0.4 -18 929 0.36 66.2 19 1074 0.413
1.4 -17 933 0.361 68 20 1078 0.415
3.2 -16 937 0.363 69.8 21 1082 0.416
5 -15 941 0.364 71.6 22 1086 0.418
6.8 -14 945 0.366 73.4 23 1090 0.419
