HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
31-00610-01 4
Controller Part Numbers
Fig. 1 Controller Part Numbers
Dimensions
Unitary Controller Large
Fig. 2 Unitary controller large dimensions
SCRW-TB-UNI-L Set of removable terminal blocks covering all models of Unitary controllers
IO-JUMPER-4-10 4-pin relay output Jumper Bar to connect 4 relays IN terminals (sold in pack of 10)
Table 2 Accessories/Replacement Parts
Part Number Description
UN- R L
UIO
16 4 4 E S B 230 N M
HOUSING
L - Large
S - Small
DO CHOPPER OUTPUT (DO CHP)
RELAY
MODBUS RTU
NIAGARA ENGINEERED
POWER SUPPLY
230 - 230 VAC
BLUETOOTH
WALL MODULE COMMUNICATION
S - Sylk
TM
BACKBONE COMMUNICATION
E - BACnet
TM
IP
T - BACnet
TM
T1L
M - BACnet
TM
MS/TP
UNITARY CONTROLLER
C
2.1 inches
(53 mm)
4.55 inches
(115.6 mm)
4.79 inches
(121.6 mm)
1.1 inches
(28 mm)
8.5 inches
(216 mm)
6.3 inches
(160 mm)
1.77 inches
(45.1 mm)
0.38 inches
(9.6 mm)
5.16 inches
(131.1 mm)
4.60 inches
(116.8 mm)
RS485
1
+
-
WM1 / 2 IO1 C IO2 IO3 C IO4 IO5 C IO6 IO7 C IO8
C IO9 C IO11 C IO12
COM
RS485 1 SYLK UIO
24VDC
OUT
24VDC
OUT
IO1
POWER 230V
NC1 NO1 IN1 NC2 NO2 IN2
NC3 NO3 IN3 NC4 NO4 IN4
DO RELAY
644645 47 48 49 50 51 52 53 55 56 57 58 59 61 62 63 65 66 67 68 69 71 7254 6 7
4321 56789 11121314151
24VDC
OUT
UIO
IO13 C IO14 IO15 C IO16
32 33 34 35 36 37 38
PORT1 PORT2
10/100 SWITCHED
DO CHP
CO3 CO4CCO1 CO2C
18 19 21 22 232
644645 47 48 49 50 51 52 53 55 56 57 58 59 61 62 63 65 66 67 68 69 71 7254 6 7
4321 56789 11121314151 32 33 34 35 36 37 38
18 19 21 22 232
N
L
V
RS485 1
POW24
