HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
31-00610-01 52
NI1000 TK5000 DIN B
R-T Characteristics of Ni1000 TK5000 DIN B.
Table 38 NI1000 TK5000 Sensor Specification
Sensor Type Nominal Resistance Sensitivity
Ni1000 TK5000 DIN B
R
0
: 1000 Ω
TC: 5000 ppm/K
Table 39 R-T Characteristics (according to supplier‘s specifications and based on DIN 43760, resistance values
in Ω)
Temp.
[°F]
Temp.
[°C]
0 -1 -2 -3 -4 -5 -6 -7 -8 -9
-58 -50 790.88
-40 -40 830.84 826.8 822.78 818.76 814.75 810.75 806.76 802.78 798.8 794.84
-22 -30 871.69 867.57 863.45 859.34 855.24 851.15 847.07 843 838.94 834.88
-4 -20 913.48 909.26 905.05 900.85 896.65 892.47 888.3 884.13 879.98 875.83
14 -10 956.24 951.92 947.61 943.31 939.02 934.74 930.47 926.21 921.96 917.72
32 0 1000 995.58 991.17 986.77 982.37 977.99 973.62 969.26 964.91 960.57
Temp.
[°F]
Temp.
[°C]
0 1 2 3 4 5 6 7 8 9
32 0 1000 1004.4 1008.9 1013.3 1017.8 1022.3 1026.8 1031.2 1035.8 1040.3
50 10 1044.8 1049.3 1053.9 1058.4 1063 1067.6 1072.2 1076.8 1081.4 1086
68 20 1090.7 1095.3 1100 1104.6 1109.3 1114 1118.7 1123.4 1128.1 1132.9
86 30 1137.6 1142.4 1147.1 1151.9 1156.7 1161.5 1166.3 1171.2 1176 1180.9
104 40 1185.7 1190.6 1195.5 1200.4 1205.3 1210.2 1215.1 1220.1 1225 1230
122 50 1235 1240 1245 1250 1255 1260.1 1265.1 1270.2 1275.3 1280.3
140 60 1285.5 1290.6 1295.7 1300.8 1306 1311.1 1316.3 1321.5 1326.7 1331.9
158 70 1337.2 1342.4 1347.6 1352.9 1358.2 1363.5 1368.8 1374.1 1379.4 1384.8
176 80 1390.1 1395.5 1400.9 1406.3 1411.7 1417.1 1422.5 1428 1433.4 1438.9
194 90 1444.4 1449.9 1455.4 1460.9 1466.5 1472 1477.6 1483.2 1488.8 1494.4
212 100 1500 1505.6 1511.3 1517 1522.6 1528.3 1534 1539.8 1545.5 1551.2
230 110 1557 1562.8 1568.6 1574.4 1580.2 1586 1591.8 1597.7 1603.6 1609.5
248 120 1615.4 1621.3 1627.2 1633.2 1639.1 1645.1 1651.1 1657.1 1663.1 1669.1
266 130 1675.2 1681.3 1687.3 1693.4 1699.5 1705.7 1711.8 1717.9 1724.1 1730.3
284 140 1736.5 1742.7 1748.9 1755.2 1761.4 1767.7 1774 1780.3 1786.6 1792.9
302 150 1799.3
