HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
47 31-00610-01
20 K NTC Characteristics
156.2 69 1813 222.8 106 571
158 70 1752 224.6 107 555
226.4 108 539 242.6 117 421
228.2 109 524 244.4 118 410
230 110 510 246.2 119 399
231.8 111 496 248 120 388
233.6 112 482 249.8 121 378
235.4 113 469 251.6 122 368
237.2 114 457 253.4 123 359
239 115 444 255.2 124 350
240.8 116 432 257 125 341
Table 35 10 K3A1 Characteristics (Continued)
Temp.
[°F]
Temp.
[°C]
Resistance
[Ω]
Temp.
[°F]
Temp.
[°C]
Resistance
[Ω]
Table 36 20 K NTC Characteristics
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
-58 -50 1659 8.78 5 -15 164 7.83
-56.2 -49 1541 8.77 6.8 -14 154 7.78
-54.4 -48 1432 8.76 8.6 -13 146 7.72
-52.6 -47 1331 8.75 10.4 -12 137 7.66
-50.8 -46 1239 8.74 12.2 -11 130 7.6
-49 -45 1153 8.72 14 -10 122 7.53
-47.2 -44 1073 8.71 15.8 -9 116 7.46
-45.4 -43 1000 8.7 17.6 -8 109 7.39
-43.6 -42 932 8.69 19.4 -7 103 7.32
-41.8 -41 869 8.67 21.2 -6 97.6 7.25
-40 -40 811 8.66 23 -5 92.3 7.17
-38.2 -39 757 8.64 24.8 -4 87.3 7.09
-36.4 -38 706 8.62 26.6 -3 82.6 7.01
-34.6 -37 660 8.6 28.4 -2 78.2 6.93
-32.8 -36 617 8.58 30.2 -1 74.1 6.85
-31 -35 577 8.56 32 0 70.2 6.76
-29.2 -34 539 8.54 33.8 1 66.5 6.67
-27.4 -33 505 8.52 35.6 2 63 6.58
-25.6 -32 473 8.49 37.4 3 59.8 6.49
-23.8 -31 443 8.47 39.2 4 56.7 6.4
-22 -30 415 8.44 41 5 53.8 6.3
