Honeywell Unitary User Manual

HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
31-00610-01 48
-20.2 -29 389 8.41 42.8 6 51.1 6.2
-18.4 -28 364 8.38 44.6 7 48.5 6.1
-16.6 -27 342 8.35 44.4 8 46 6
-14.8 -26 321 8.32 48.2 9 43.7 5.9
-13 -25 301 8.28 50 10 41.6 5.8
-11.2 -24 283 8.25 51.8 11 39.5 5.7
-9.4 -23 266 8.21 53.6 12 37.6 5.59
-7.6 -22 250 8.17 55.4 13 35.7 5.49
-5.8 -21 235 8.13 57.2 14 34 5.38
-4 -20 221 8.08 59 15 32.3 5.28
-2.2 -19 208 8.04 60.8 16 30.8 5.17
-0.4 -18 196 7.99 62.6 17 29.3 5.07
1.4 -17 184 7.94 64.4 18 27.9 4.96
3.2 -16 174 7.89 66.2 19 26.6 4.85
68 20 25.3 4.75 134.6 57 5.08 1.66
69.8 21 24.2 4.64 136.4 58 4.88 1.61
71.6 22 23 4.53 138.2 59 4.69 1.56
73.4 23 22 4.43 140 60 4.52 1.51
75.2 24 21 4.32 140 60 4.52 1.51
77 25 20 4.22 141.8 61 4.35 1.46
78.8 26 19.1 4.12 143.6 62 4.18 1.41
80.6 27 18.2 4.01 145.4 63 4.03 1.37
82.4 28 17.4 3.91 147.2 64 3.88 1.32
84.2 29 16.6 3.81 149 65 3.73 1.28
86 30 15.9 3.71 150.8 66 3.59 1.24
87.8 31 15.2 3.62 152.6 67 3.46 1.2
89.6 32 14.5 3.52 154.4 68 3.34 1.16
91.4 33 13.9 3.43 156.2 69 3.21 1.13
93.2 34 13.3 3.33 158 70 3.1 1.09
95 35 12.7 3.24 159.8 71 2.99 1.06
96.8 36 12.1 3.15 161.6 72 2.88 1.02
98.6 37 11.6 3.06 163.4 73 2.78 0.991
100.4 38 11.1 2.97 165.2 74 2.68 0.96
102.2 39 10.7 2.89 167 75 2.58 0.929
104 40 10.2 2.81 168.8 76 2.49 0.9
105.8 41 9.78 2.72 170.6 77 2.41 0.872
107.6 42 9.37 2.64 172.4 78 2.32 0.844
Table 36 20 K NTC Characteristics (Continued)
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]

Honeywell Unitary Specifications

General

Brand	Honeywell
Model	Unitary
Category	Controller
Language	English
