HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
49 31-00610-01
109.4 43 8.98 2.57 174.2 79 2.24 0.818
111.2 44 8.61 2.49 176 80 2.17 0.792
113 45 8.26 2.42 177.8 81 2.09 0.767
114.8 46 7.92 2.34 179.6 82 2.02 0.744
116.6 47 7.6 2.27 181.4 83 1.95 0.72
118.4 48 7.29 2.2 183.2 84 1.89 0.698
120.2 49 7 2.14 185 85 1.82 0.676
122 50 6.72 2.07 186.8 86 1.76 0.655
123.8 51 6.45 2.01 188.6 87 1.7 0.635
125.6 52 6.19 1.94 190.4 88 1.65 0.616
127.4 53 5.95 1.88 192.2 89 1.59 0.597
129.2 54 5.72 1.82 194 90 1.54 0.578
131 55 5.49 1.77 195.8 91 1.49 0.561
132.8 56 5.28 1.71 197.6 92 1.44 0.544
199.4 93 1.4 0.527 251.6 122 0.57 0.225
201.2 94 1.35 0.511 253.4 123 0.56 0.219
203 95 1.31 0.496 255.2 124 0.54 0.213
204.8 96 1.27 0.481 257 125 0.53 0.207
206.6 97 1.23 0.466 258.8 126 0.51 0.201
208.4 98 1.19 0.452 260.6 127 0.5 0.196
210.2 99 1.15 0.439 262.4 128 0.49 0.191
212 100 1.11 0.425 264.2 129 0.47 0.186
213.8 101 1.08 0.413 266 130 0.46 0.181
215.6 102 1.05 0.401 267.8 131 0.45 0.176
217.4 103 1.01 0.389 269.6 132 0.43 0.171
219.2 104 0.98 0.378 271.4 133 0.42 0.167
221 105 0.95 0.367 273.2 134 0.41 0.162
222.8 106 0.92 0.356 275 135 0.4 0.158
224.6 107 0.9 0.346 276.8 136 0.39 0.154
226.4 108 0.87 0.336 278.6 137 0.38 0.15
228.2 109 0.84 0.326 280.4 138 0.37 0.146
230 110 0.82 0.317 282.2 139 0.36 0.142
231.8 111 0.79 0.308 284 140 0.35 0.139
233.6 112 0.77 0.299 285.8 141 0.34 0.135
235.4 113 0.75 0.29 287.6 142 0.33 0.132
237.2 114 0.73 0.282 289.4 143 0.32 0.128
239 115 0.7 0.274 291.2 144 0.32 0.125
Table 36 20 K NTC Characteristics (Continued)
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
voltage [V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage [V]
