HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
31-00610-01 6
SPECIFICATIONS
Electrical
Operational Environment
Hardware
Communications
Table 3 Electrical Specification
Parameter Specification
Rated input voltage 230 VAC ± 10 %
Maximum Nominal
Power Consumption
(for IP, MS/TP, and T1L
models)
Small:
IP and T1L: 45 VA
MS/TP : 60 VA
Large:
IP and T1L: 60 VA
MS/TP: 75 VA
Full Load Power
Consumption
(Maximum load
including external
loads, Sylk™, Bluetooth,
Communication,
Universal IO output,
24 VDC output, and load
on the DO CHPs) for IP,
MS/TP, and T1L.
Small:
IP: 170 VA
MS/TP, and T1L: 200 VA
Large:
IP: 200 VA
MS/TP and T1L: 210 VA
Frequency Range 50/60 Hz
Auxiliary Output
24 VDC at 75 mA (shared
between terminals 38, 48,
65 and 72)
Type of loads Resistive or inductive loads
Impulse Voltage 4000 V (4 kV)
Material Group IIIb
Period of electric stress
across insulating parts
Long
Classes of control
function
Class A control
Type of Output
Waveform
Rectangle
Table 4 Operational Environment
Parameter Specification
Storage
Temperature
-40 °F to 150 °F (-40 °C to 66 °C)
Operation
Temperature
-40 °F to 149 °F (-40 °C to 65 °C)
with 0.6 A cumulated across all
chopper outputs.
-40 °F to 122 °F (-40 °C to 50 °C)
with 1.5 A cumulated across all
chopper outputs.
Humidity 5 % to 95 % RH, non-condensing
Protection IP20, NEMA 1
Pollution
degree
2
Additional
tests
conducted
Ball Pressure and Glow wire test
Table 5 Hardware Specification
Parameter Specification
CPU
Crossover processor i.MXRT ARM
CORTEX-M7
Memory
Capacity
16 MB QSPI Flash, 16 MB SDRAM
Ethernet
BACnet™ IP (RJ45): 2 x RJ-45
Ethernet ports with a protection that
allows loop topology to continue the
communication with other
controllers even if one node fails,
when used with an RSTP supporting
device.
Real Time
Clock
24 hours backup after power failure.
After 24 hours, the time will reset to
factory default time until the user
performs a BACnet™ Time Sync
Small LED
Transmission or reception of
communication signal (green)
Large LED
Controller status (Green, Yellow, and
Red)
Table 6 Communication Specification
Parameter Specification
Protocol supported
• BACnet™ IP (RJ45 or T1L)
• BACnet™ MS/TP*
• Modbus RTU (Modbus
client)
• Bluetooth (Optional)
IP Addressing
Modes
• Dynamic: DHCP and Link
Local
• Static: Assigned
Sylk™ bus 2-wire, polarity-insensitive
*Auto Baud rate detection is provided for the
BACnet™ MS/TP controllers.
Table 4 Operational Environment
