HONEYWELL UNITARY CONTROLLER - 230 VAC - INSTALLATION INSTRUCTIONS
43 31-00610-01
33.8 1 31.027 5.189 91.4 33 7.098 2.159
93.2 34 6.808 2.091 159.8 71 1.694 0.632
95 35 6.531 2.025 161.6 72 1.637 0.612
96.8 36 6.267 1.962 163.4 73 1.583 0.593
98.6 37 6.015 1.9 165.2 74 1.531 0.575
100.4 38 5.775 1.84 167 75 1.481 0.557
102.2 39 5.546 1.781 168.8 76 1.433 0.541
104 40 5.327 1.724 170.6 77 1.387 0.524
105.8 41 5.117 1.669 172.4 78 1.342 0.508
107.6 42 4.917 1.616 174.2 79 1.299 0.493
109.4 43 4.726 1.564 176 80 1.258 0.478
111.2 44 4.543 1.514 177.8 81 1.218 0.464
113 45 4.369 1.465 179.6 82 1.179 0.45
114.8 46 4.202 1.418 181.4 83 1.142 0.436
116.6 47 4.042 1.373 183.2 84 1.107 0.423
118.4 48 3.889 1.329 185 85 1.072 0.411
120.2 49 3.743 1.286 186.8 86 1.039 0.399
122 50 3.603 1.244 188.6 87 1.007 0.387
123.8 51 3.469 1.204 190.4 88 0.976 0.375
125.6 52 3.34 1.166 192.2 89 0.947 0.365
127.4 53 3.217 1.128 194 90 0.918 0.354
129.2 54 3.099 1.092 195.8 91 0.89 0.344
131 55 2.986 1.057 197.6 92 0.863 0.334
132.8 56 2.878 1.023 199.4 93 0.838 0.324
134.6 57 2.774 0.99 201.2 94 0.813 0.315
136.4 58 2.675 0.959 203 95 0.789 0.306
138.2 59 2.579 0.928 204.8 96 0.765 0.297
140 60 2.488 0.898 206.6 97 0.743 0.289
141.8 61 2.4 0.87 208.4 98 0.721 0.28
143.6 62 2.316 0.842 210.2 99 0.7 0.276
145.4 63 2.235 0.815 212 100 0.68 0.265
147.2 64 2.158 0.79 156.2 69 1.813 0.673
149 65 2.083 0.765 158 70 1.752 0.652
150.8 66 2.011 0.74
152.6 67 1.943 0.718
154.4 68 1.877 0.695
Table 33 10 K NTC TYPE II Characteristics (Continued)
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage
[V]
Temp.
[°F]
Temp.
[°C]
Resistance
[KΩ]
Terminal
Voltage
[V]
