Jetdirect EIO Menus for Classic Control Panels
Classic control panels are provided on older devices that support HP Jetdirect EIO print servers only.
Classic control panels can typically display two lines of 16 characters each. You must use the available
device keys to display and select HP Jetdirect settings. Typically, an asterisk (*) is used to identify the
selected value.
Figure C-2 Example of Classic Control Panel
Table C-2 HP Jetdirect EIO Menu on Classic Control Panel
Menu Item Description
CFG NETWORK
Selects whether or not you want to access the Jetdirect menu.
NO (default): Bypass the HP Jetdirect menu.
YES: Access the HP Jetdirect menu. You must change this to YES* each time you want to access
the menu.
TCP/IP
IPX/SPX
DLC/LLC
ATALK
Identifies whether the protocol stack is enabled or disabled.
ON: The protocol is enabled.
OFF: The protocol is disabled.
NOTE: The factory default setting depends on the print server model. For example,
only TCP/IP is enabled on HP Jetdirect 635n print servers.
CFG TCP/IP Selects whether you want to access the TCP/IP menu and set TCP/IP protocol parameters.
NO (default): Bypass the TCP/IP menu items.
YES: Access the TCP/IP menu items.
●
BOOTP=YES* enables IPv4 configuration by a BootP Server.
●
DHCP=YES* enables IPv4 configuration by a DHCP Server.
If DHCP=YES* and the print server has a DHCP lease, you can choose to configure the
following DHCP settings:
●
RELEASE: Choose YES to release, or NO to save, the current DHCP lease.
●
RENEW: Choose YES to renew the current DHCP lease, or NO to not renew the DHCP
lease.
●
AUTO IP=YES* will automatically assign a link-local IPv4 address in the form 169.254.x.x.
178 Appendix C HP Jetdirect Control Panel Menus (V.36.xx) ENWW
