Table 8-11 AppleTalk Configuration Information
Message Description
STATUS Indicates the current AppleTalk configuration status.
READY: Indicates the HP Jetdirect print server is awaiting data.
DISABLED: Indicates that AppleTalk was manually disabled.
INITIALIZING: Indicates that the print server is registering the node address or name.
An additional status message may also be displayed.
An error code and message is displayed if the print server is not ready. For more
information, see
Table 8-13 Error Messages on page 140.
NAME The name of the printer on the AppleTalk network. A number after the name indicates
that there are multiple devices with this name, and this is the Nth instance of the name.
ZONE The name of the AppleTalk network zone on which the printer is located.
TYPE The type of the printer being advertised on the network. Two types can be displayed.
NETWORK NUMBER
NODE NUMBER
NETWORK NUMBER: Identifies the AppleTalk Network Number on which the HP
Jetdirect print server is currently operating.
NODE NUMBER: Identifies the AppleTalk Node Number that the print server chose for
itself as part of its initialization sequence.
NOTE: The AppleTalk phase 2 (P2) parameter is pre-configured on the HP
Jetdirect print server.
DLC/LLC Protocol Information
Information in this section of the Jetdirect configuration page is described in Table 8-12 DLC/LLC
Configuration Information on page 139.
Table 8-12 DLC/LLC Configuration Information
Message Description
STATUS: Indicates the current DLC/LLC protocol status.
READY: Indicates the HP Jetdirect print server is awaiting data.
DISABLED: Indicates that DLC/LLC was manually disabled.
INITIALIZING: Indicates that the print server is registering the node address or name.
An additional status message may also be displayed.
An error code and message is displayed if the print server is not ready. For more
information, see
Table 8-13 Error Messages on page 140.
Error Messages
Error codes and messages that may appear in the Status sections of the Jetdirect configuration page
are described in
Table 8-13 Error Messages on page 140.
ENWW HP Jetdirect Configuration Page 139
