BOOTP/TFTP on UNIX
This section describes how to configure the print server using BOOTP (Bootstrap Protocol) and TFTP
(Trivial File Transfer Protocol) services on UNIX servers. BOOTP and TFTP are used to download
network configuration data from a server to the HP Jetdirect print server over the network.
Systems That Use Network Information Service (NIS)
If your system uses NIS, you may need to rebuild the NIS map with the BOOTP service before performing
the BOOTP configuration steps. Refer to your system documentation.
Configuring the BOOTP Server
For the HP Jetdirect print server to obtain its configuration data over the network, the BOOTP/TFTP
servers must be set up with the appropriate configuration files. BOOTP is used by the print server to
obtain entries in the /etc/bootptab file on a BOOTP server, while TFTP is used to obtain additional
configuration information from a configuration file on a TFTP server.
When the HP Jetdirect print server is powered on, it broadcasts a BOOTP request that contains its MAC
(hardware) address. A BOOTP server daemon searches the /etc/bootptab file for a matching MAC
address, and if successful, sends the corresponding configuration data to the Jetdirect print server as
a BOOTP reply. The configuration data in the /etc/bootptab file must be properly entered. For a
description of entries, see “
Bootptab File Entries (IPv4) on page 25”.
The BOOTP reply may contain the name of a configuration file containing enhanced configuration
parameters. If the HP Jetdirect print server finds such a file, it will use TFTP to download the file and
configure itself with these parameters. For a description of entries, see “
TFTP Configuration File Entries
(IPv4) on page 27”. Configuration parameters retrieved through TFTP are optional.
NOTE: HP recommends that the BOOTP server be located on the same subnet as the printers
it serves. BOOTP broadcast packets may not be forwarded by routers unless the routers
are properly configured.
Bootptab File Entries (IPv4)
An example of a /etc/bootptab file entry for IPv4 configuration of an HP Jetdirect print server is
provided below:
picasso:\
:hn:\
:ht=ether:\
:vm=rfc1048:\
:ha=0001E6123456:\
:ip=192.168.40.39:\
:sm=255.255.255.0:\
:gw=192.168.40.1:\
:lg=192.168.40.3:\
:T144="hpnp/picasso.cfg":
Note that the configuration data contains “tags” to identify the various HP Jetdirect parameters and their
settings. Entries and tags supported by the HP Jetdirect print server are listed in the following table.
ENWW IPv4 Configuration 25
