Figure 30 Cable Connection Examples for Redundant and Meshed Topologies
Table 23 Cable Connection for Redundant and Meshed Topologies Label and Description
DescriptionLabel
2-switch mesh1
3-switch mesh2
4-switch mesh3
5-switch mesh4
Sample Network Topologies
This section shows a few sample network topologies in which the switch is implemented. For
more topology information, visit the product’s website at http://www.hpe.com/networking/support.
The switch is designed to be used primarily as a desktop switch to which end nodes, printers
and other peripherals, and servers are directly connected, as shown in the following illustration.
