HP Engage Flex Pro G2 - Page 10

Table 1-2 Identifying the rear panel components
Rear panel components
1 PCIe® x16 expansion slot (optional) 10 USB 5 Gbps ports (3)
2 PCIe x4 expansion slot (optional)* 11 USB 5 Gbps port with HP Sleep and Charge
3 Audio-out (headphone)/Audio-in (microphone)
combo jack
12 Flex Port 2
● USB Type-C
®
65 W power delivery port
(shown)
● Serial port
● DisplayPort™ connector
● High-Definition Multimedia Interface®
(HDMI®)
● 2nd network port
● VGA port
4 PCIe x1 expansion slot (optional) 13 Serial port (optional)
5
PCIe x1 expansion slot (optional)
14 DisplayPort connector
Rear panel components 3
