3. Remove the speaker from the connectors (3).
To install the speaker, reverse the removal procedure.
Optical drive cage
To remove the optical drive cage, use this procedure and illustration.
Before removing the optical drive cage, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 20).
2. Remove the access panel (see Access panel on page 21).
3. Remove the optical drive (see Optical drive on page 23).
Remove the optical drive cage:
1. Press the green release button (1).
Optical drive cage
43
